[4XC7A08241] ThinkSystem Broadcom 57454 10/25GbE SFP28 4-port PCIe Ethernet Adapter

Specifications

Processor / Memory
Processor 1 x BCM57454 - Broadcom

Miscellaneous
Included Accessories Low-profile bracket
Compliant Standards BSMI CNS 13438 Class B, ICES-003, RRL, CSA 22.2 No. 950, ICES-003 Class B, EN55024 Class B, UL 60950-1, EN 60950-1, FCC CFR47 Part 15 B, cTUVus, UL 94, KN22, KN24, EN 55022:2010+AC:2011 Class B, UL 1977, UL 796, CNS 14336 Class B
Networking
Ports 10/25 Gigabit SFP28 x 4
Connectivity Technology Wired
Data Link Protocol 10 Gigabit Ethernet, 25 Gigabit Ethernet
Data Transfer Rate 25 Gbps
Capacity Jumbo frame size: 9600
Features Single Root I/O Virtualization (SR-IOV), Data Center Bridging (DCB), Extended Message-Signaled Interrupts (MSI-X), Edge Virtual Bridging (EVB), RDMA over Converged Ethernet (RoCE), Priority-Based Flow Control (PFC), RDMA over Converged Ethernet (RoCE) v2, TruFlow, Enhanced transmission selection (ETS)
Compliant Standards IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg

Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 5 - 95% (non-condensing)
General
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type PCI Express 3.0 x16
Expansion / Connectivity
Interfaces 4 x 10Gb Ethernet/25Gb Ethernet - SFP28
