[4XC7A08225] ThinkSystem QLogic QL41134 PCIe 10Gb 4-Port Base-T Ethernet Adapter

Specifications

Networking
Ports Gigabit Ethernet / 10Gb Ethernet x 4
Connectivity Technology Wired
Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet
Data Transfer Rate 10 Gbps
Performance Packets per second: 60000000
Capacity Jumbo frame size: 9600
Remote Management Protocol CLI
Features Flow control, Data Center Bridging Exchange (DCBX) support, PXE support, Large Send Offload (LSO), Giant Send Offload (GSO), Large Receive Offload (LRO), Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), Data Center Bridging (DCB), congestion control, TCP Segmentation Offload (TSO), Class of Service (CoS), Extended Message-Signaled Interrupts (MSI-X), Edge Virtual Bridging (EVB), Generic Routing Encapsulation (GRE), Precision Time Protocol (PTP), Transmit Side Scaling (TSS), iSCSI boot, TCP/IP checksum offload, UDP/IP checksum offload, RDMA over Converged Ethernet (RoCE), Unified Fabric Port (UFP), Priority-Based Flow Control (PFC), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), Link Aggregation, Receive Side Coalescing (RSC), iWARP support, Energy-Efficient Ethernet (EEE), Network Partitioning (NPAR), Data Plane Development Kit (DPDK), iSCSI Extensions over RDMA (iSER), VLAN Tagging, Interrupt coalescing, Active State Power Management (ASPM) support, Stateless Transport Tunneling, Enhanced transmission selection (ETS), Quantized Congestion Notification (QCN)
Compliant Standards IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3an, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.3-2015

Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 10 - 80% (non-condensing)
General
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type PCI Express 3.0 x8
PCI Specification Revision PCIe 3.0
Expansion / Connectivity
Interfaces 4 x 10GBase-T - RJ-45
