Western Digital RE4-GP WD2002FYPS SATA Hard Drive
Interface : SATA 3 Gb/s
Formatted capacity : 2 TB
User sectors per drive : 3,907,029,168
Native command queuing : Yes
SATA latching connector : Yes
Form factor : 3.5-inch
RoHS compliant : Yes
Data transfer rate (max) Buffer to host Host to/from drive (sustained) : 3 Gb/s 110 MB/s
Cache (MB) : 64
Rotational speed (RPM) : IntelliPower
Average drive ready time (sec) : 17
Heads/disks : 8/4
Bytes per sector (STD) : 512
Load/unload cycles : 600,000
Non-recoverable read errors per bits read : <1 in 10^15
12VDC (A, max) : 1.8
Average power requirements (W) Read/Write Idle Standby Sleep : 6.8 3.7 0.8 0.8
Temperature (°C) Operating Non-operating : 5 to 55 -40 to 70
Shock (Gs) Operating (2 ms, read) Operating (2 ms, read/write) Non-operating (2 ms) : 30 65 300
Average acoustics (dBA) Idle mode Performance seek mode Quiet seek mode : 25 29 26
Height (in./mm, max) : 1.028/26.1
Length (in./mm, max) : 5.787/147
Width (in./mm, ± .01 in.) : 4/101.6
Weight (lb./kg, ± 10%) : 1.61/0.73
