Western Digital WD Re WD1004FBYZ 1TB SATA Hard Disk Drive
Interface : SATA 6 Gb/s
Formatted capacity : 1TB
512n/512e user sectors per drive : 1,953,525,168
Native command queuing : Yes
Form factor : 3.5-inch
RoHS compliant : Yes
Data transfer rate (max) - Buffer to host - Host to/from drive (sustained) : - 6 Gb/s - 184 MB/s
Cache (MB) : 128
Rotational speed (RPM) : 7200
Load/unload cycles : 600,000
Non-recoverable read errors per bits read : <1 in 10^15
MTBF (hours) : 2,000,000
AFR (%) : 0.44
Average power requirements (W) - Sequential read - Sequential write - Random read/write - Idle : - 7.4 - 7.4 - 8.1 - 5.9
Temperature (°C) - Operating - Non-Operating : - 5 to 60 - -40 to 70
Shock (Gs) - Operating (2 ms, read/write) - Operating (2 ms, read) - Non-Operating (2 ms) : - 30 - 65 - 300
Acoustics (dBA) - Idle - Seek (average) : - 25 - 28
Height (in./mm, max) : 1.028/26.1
Length (in./mm, max) : 5.787/147
Width (in./mm, ± .01 in.) : 4/101.6
Weight (lb/kg, ± 10%) : 1.41/0.64
