SEAGATE ST2000NX0433 - 2TB 7.2K SFF SAS 12G HDD ST2000NX0433
Drive Dimensions : 2.5inx15mm
Specification : 5xx Emulation
Capacity : 2 TB/2,000 GB
PowerChoice on demand power option : Yes
Protection Information : Yes
Low Halogen : Yes
RAID Rebuild : Yes
Mean Time Between Failures (MTBF, hours) : 1.4 million
Reliability Rating @ Full 24x7 operation (AFR) : 0.63%
Nonrecoverable Read Errors per Bits Read : 1 sector per 10e15
Power-On Hours per Year : 8760
Bytes per Sector : 512, 520, 528
Spindle Speed (RPM) : 7200
Cache Buffer, Multisegmented (MB) : 128
Interface Access Speed (Gb/s) : 12.0, 6.0, 3.0
Max. Sustained Transfer Rate (MB/s) : 136
Average Latency (ms) : 4.16
Interface Ports : Dual
RV Tolerance (rad/s to 1800Hz) : 16
Idle Power (W) : 3.53
Typical Operating, Random Read (W) : 6.02
PowerChoice Technology (Standby) (W) : 1.52
Power Supply Requirements : +12V and +5V
Temperature, Operating (°C) : 5 to 55
Vibration, Operating, 5Hz to 500Hz (Gs) : 0.5
Vibration, Nonoperating, 5Hz to 500Hz (Gs) : 3.0
Shock, Operating, 2ms (Gs) : 25
Shock, Nonoperating, 2ms (Gs) : 400
Acoustics, Typical Idle (bels) : 2.8
Acoustics, Typical Seel (bels) : 3.2
Height (in/mm) : 0.591/15.00
Width (in/mm) : 2.760/70.10
Depth (in/mm) : 3.955/100.45
Weight (lb/kg) : 0.437/0.198
