IBM 7226-1U3 Multi-Media Storage Expansion Enclosure - CTO
Model / Part Number : 7226-1U3 / LTO-9 SAS drive feature (8641, 02XW382, or similar)
Form Factor : 1U rack-mountable (1.75" height)
Drive Bays : Two bays (configured here with LTO-9 SAS tape drive(s))
Tape Drive : Half-high LTO Ultrium 9 SAS
Interface : SAS (6/12 Gbps supported in configurations)
Native Capacity (per cartridge) : 18 TB
Compressed Capacity (per cartridge) : 45 TB (2.5:1 compression)
Native Data Rate : Up to 400 MB/s (typical for LTO-9 HH)
Compressed Data Rate : Up to 1,000 MB/s (typical for LTO-9 HH)
Media Compatibility : LTO-9 (R/W), LTO-8 (R/W including Type M), LTO-7 (R)
Physical Dimensions : 438 mm (width) x 480 mm (depth) x 43 mm (height)
Power Supply : Single (redundant options in some configs)
